产品描述
技术参数 Technical Data
| Description/描述 | Value/值 | ||||||
| Number of gear stages/齿轮级数 | 1 | 2 | 3 | 4 | 5 | ||
| Reduction ratio/减速比 | 4 | 16 | 64 | 256 | 1024 | ||
| No-load gear backlash/空载时齿轮回差 | 1.8° | 2.2° | 2.4° | 2.5° | 2.5° | ||
| Max. continuous input speed/最大连续输入转速 | 12,000rpm | 15,000rpm | 18,000rpm | 20,000rpm | 25,000rpm | ||
| Max. instantaneous input speed/最大瞬时输入转速 | 15,000rpm | 20,000rpm | 22,000rpm | 25,000rpm | 30,000rpm | ||
| Max. continuous torque/最大连续扭矩 | 50mNm | 100mNm | 200mNm | 300mNm | 400mNm | ||
| Max. instantaneous torque/最大瞬时扭矩 | 75mNm | 150mNm | 300mNm | 450mNm | 600mNm | ||
| Max. efficiency/最大效率 | 85% | 72% | 61% | 52% | 44% | ||
| Weight reference value of gearbox/齿轮箱重量参考值(g) | 9.5 | 11.6 | 13.9 | 16.1 | 18.4 | ||
| L1[mm]=Lenght of gearbox/齿轮箱长度 | 13.2 | 17.05 | 20.9 | 24.75 | 28.6 | ||
电机齿轮参数 Motor pinion specifications
|
Initial deceleration ratio 初段减速比 |
Material 材料 |
Number of teeth 齿数 |
Thickness 厚度 |
Hole size 孔径 |
||||
| 4 | Steel/钢件 | Z=15 |  |
 |
||||
 |
||||||||
 |
 |
我司可根据客户要求设计和生产相关产品，可适配多类型电机。
